A4Tech X5-35WD Manual de usuario

2-Wheel Run on Shine

User’s Manual

Model: X5-35WD

www.a4tech.com

HOW TO CONNECT YOUR MOUSE

1. Locate an available USB mouse port on the back of your computer.

2. Insert the USB mouse connector into the USB port .

If you like to use the PS2 port (for the round PS/2 plug), you will need to plug the USB

connector with a PS2 adapter.

HOW TO USE YOUR IWHEELWORKS 5KEYS MOUSE?

Control the Horizontal

movement from the

left , right direction Just one click on “2X Button”

without any driver. straightly open

files and programs easily. Save

times and improve efficiency.

Control the vertical

movement from up to

down direction

STEP ONE: HOW TO INSTALL IWHEELWORKS SOFTWARE

***** For Windows 98/ME/2000/2003/XP/X64

1. MUST: Please uninstall any previous mouse drivers totally before installing the iwheelworks

2. MUST: Make sure you have completely finished setting up your mouse pad and mouse

3. Insert the included Compact Disc (CD) into your CD-ROM

4. Click “Install Driver”.

5. Select item “2wheel 5buttton(4D++)” at wired mouse to install the driver for X5-35D/X6-35WD

mouse;

6. Restart your computer after the driver has been installed

7. You will see a mouse icon “ ” appear on the bottom right of your task bar (near the clock area)

8. Double click on the mouse icon “ ” will bring you the mouse property

(Image: Mouse Properties Window)

9. If the mouse image appears in the mouse properties menu looks exactly

the same as the mouse on hand, then you have successfully installed the

iwheelworks driver

Select 2 wheel 5button

For X5-35WD mouse

STEP TWO: HOW TO PROGRAM YOUR MOUSE BUTTONS

zOpen your Mouse Properties.

Section I: Button Assignment

1. The mouse image that appears in the first section is a key

to numbers listed to the right.

# 1 button has been assigned as “Main Button” by default and

it’s not programmable.

# 2 button has been assigned as “Right Button” which works

as right click for your mouse

# 3 button has been assigned as “Pan” function by default. It’s

a vertical scrolling wheel if you scroll it. Also, # 3 wheel button

can be using as a “Net/LuckyJump”, you need to open the

Mouse Properties window and select the Button tab as left

image shown. Then assign Net/LuckyJump in 3rd wheel

button command. You also can use “Setting” to update the

command list of Net/LuckJump. Press the wheel button, it will

show up NetJump or LuckyJump screen which shows 14

commonly used tasks as for convenient shortcuts. The 4th &

5th Buttons ：The 4th and 5th buttons can be programmable

with more than 58 various shortcuts/commands

Executing Net Jump Commands

Netjump combines commonly used tasks for Web browsing

into one convenient grid and puts them right under the mouse

cursor. To use Netjump , open the Mouse Properties window

and select “ Buttons” tab . Assign Netjump in the drop-down

menu of the button you want. Click OK to close the Mouse

Properties window . Now click the assigned button to open

Netjump grid and execute your command. ( See the setting

tab section on the right figure ).

Executing Lucky Jump Commands

Luckyjump combines commonly used tasks for Windows

environment into one convenient grid and puts them right

under the mouse cursor. To use Luckjump , open the Mouse

Properties window and select “ Buttons” tab .Assign

Luckjump in the drop-down menu of the button you want.

Click OK to close the Mouse Properties window . Now click

the assigned button to open Luckyjump grid and execute your

command.

Section II: Double-Click Speed Section III: Button Configuration

Adjust your double-click speed If you select “Left-Handed”, your Main Button will be #2 button.

TECH SUPPORT

For tech support, please visit our website at http://support.a4tech.com/ or email us at [email protected]
