A4Tech BT-630 Manual de usuario

Bluetooth Mouse User Guide

Model: BT-630

www.a4tech.com

All manuals and user guides at all-guides.com

all-guides.com

—

1 —

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO

THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL

INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,

INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

Federal Communications Commission Requirements

The equipment has been tested and found to comply with the limits for Class B Digital Device

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates uses and can radiate radio frequency energy and if not installed and used in

accordance with the instruction may cause harmful interference to radio communication.

However there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception which can

be determined by turning the equipment off and on the user is encouraged to try to correct

the interference by one or more of the following measures:

●Reorient of relocate the receiving antenna.

●Increase the separation between the equipment and receiver.

●Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

●Consult the dealer or an experienced radio/TV technician for help.

THE CHANGES OR MODIFICATIONS NOT E PRESSLY APPROVED BY THE PARTY

All manuals and user guides at all-guides.com

—

2 —

RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE

EQUIPMENT.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference and

(2) This device must accept any interference received including interference that may cause

undesired operation.

FCC Radiation Exposure Statement

The equipment complies with FCC radiation exposure limits set forth for uncontrolled

equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to

OET65. The equipment has very low levels of RF energy that it is deemed to comply without

testing of specific absorption ratio (SAR).

Package Contents

1. Bluetooth Mouse

2. 1*AA Battery

3. Quick Set Up Guide

4. CD (CD User Manual)

Features

1. Bluetooth V2.0 10 meter range

All manuals and user guides at all-guides.com

—

3 —

2. 1000DPI

3. Four stages power saving mode low battery warning

4. 8 in Right software innovative 4D wheel

System Requirement

: Windows XP/ Vista / Windows 7

Know your product

All manuals and user guides at all-guides.com

—

4 —

Front View

Back View

Dual-color LED Indicator

Bluetooth Mouse LED Status

Power On Green LED: Turn off after 1 Second

Low Battery Warning Red LED: Blinking

Connection Start Alternate Blink Between Red and Green

Connection Complete Stop Blinking

Turn On/Off Mouse

All manuals and user guides at all-guides.com

—

5 —

1. Slide on the power switch to immediately turn on the

mouse.

2. To turn off the mouse just slide off the power switch and

then LED light is off immediately.

Battery Installation

Open battery cover and insert the supplied AA battery. Please make sure that the positive (+)

and negative (-) ends of the battery match the polarity indicators inside the battery

compartment.

Power Saving Management

Four stages power saving mode provide the best power saving management. In Deep Sleep the

mouse can

be activated by clicking any mouse buttons. In other sleep statuses just move the mouse to

activate

it.

All manuals and user guides at all-guides.com

all-guides.com

—

6 —

Note:

The mouse will enter Deep Sleep ten seconds after turning off PC. To wake it up turn

on PC and click any mouse button.

Status Time elapses to enter the

mode Power Consumption

Way to wake up

Stand-by 0 second 20mA Moving

Slight Sleep 2 seconds 10mA Moving

Middle Sleep 4 seconds 1.7mA Moving

Deep Sleep 5 minutes 0.3mA Clicking

All manuals and user guides at all-guides.com

—

7 —

Configuration

Our Bluetooth Mouse is designed to work with Five major software standards: Microsoft

Broadcom IVT Toshiba Apple. Please select the corresponding connection way according to

your software standard.

Bluetooth

Software

Vendor

Bluetooth

Software

Name

Bluetooth

Device Not

Inserted

Bluetooth

Device

Already

Inserted

Bluetooth

Device In

Working

Support

Version

Microsoft Windows

Bluetooth

Windows

XP(SP2) Above

Broadcom Widcomm

V4.0 Above

IVT BlueSoleil

V5.0 Above

Toshiba

Bluetooth

Stack

V3.0 Above

Apple Mac OS X

Bluetooth

Mac

OS X

10.4~10.5

Above

All manuals and user guides at all-guides.com

—

8 —

Note：

：：

：Before start Bluetooth Mouse connectivity please check whether your system has

already installed Bluetooth software and whether it works.

Bluetooth Software: MICROSOFT

Step 1：Click

Start

click

Control Panel

(make sure you're in Classic View) and

then double-click Bluetooth Devices.

Step 2：In popped

Bluetooth Devices

window Click Add.

All manuals and user guides at all-guides.com

—

9 —

Step

：

Turn on the mouse and press the

connection button at the bottom of mouse

until the LED Indicator in the middle

wheel blinks alternately in Red and

Green. In the Add Bluetooth Device

Wizard select the My device is set up and

ready to be found check box and then

click Next.

Step 4

：

After th

e device names appear click

Bluetooth Mouse and then click Next.

All manuals and user guides at all-guides.com
