9dot 8INJ Manual de usuario

8INJ MANUAL VER. 2 REV. 0

Important notes .........................................................................................................................................................................3

Safety ..........................................................................................................................................................................................4

General warnings and precautions ............................................................................................................................................4

Certifications and compliances ..................................................................................................................................................4

Guarantee ...................................................................................................................................................................................4

General description ....................................................................................................................................................................5

Features 8INJ ..............................................................................................................................................................................7

Manages any kind of PoE .................................................................................................................................................................................................................. 7

Surge protection ................................................................................................................................................................................................................................. 7

More power ........................................................................................................................................................................................................................................ 7

Compact design ................................................................................................................................................................................................................................. 7

Label ........................................................................................................................................................................................................... 8

Technical specifications .............................................................................................................................................................9

Installation ............................................................................................................................................................................... 10

Typical configuration ........................................................................................................................................................................................................................ 10

Physical interface ..................................................................................................................................................................... 11

LED coding ............................................................................................................................................................................................... 11

Power input .............................................................................................................................................................................. 11

Special case -48V ............................................................................................................................................................................................................................ 11

Output power ........................................................................................................................................................................... 11

GigaKey ............................................................................................................................................................................................................................................ 11

Official distributors .................................................................................................................................................................. 13

8INJ MANUAL VER. 2 REV. 0

Important notes

 Warnings and cautions must be read and understood before installing 9dot products. Otherwise, personal injury could

occur.

 The photographs, diagrams and figures contained in this manual are for illustrative purposes only. They may not

match to your installation.

 9dot will not be liable for eventual damage or injury involving its hardware if it is used in any way inconsistent with

its intended purpose, or if it is installed or used in an untested manner or is improperly maintained.

 The material in this document is for informational purposes only and is subject to change without notice. While

reasonable efforts have been made in the preparation of this document to ensure its accuracy, 9dot assumes no

responsibility for errors or omissions in this document or for the use of the information contained therein. 9dot

reserves the right to make changes to the design of the product without reservation and without prior notice to its

users.

 The operator is advised to review the drawings and illustrations contained in this manual before proceeding. If you

have any questions regarding the safe operation of this power system, please contact 9dot or your nearest 9dot

distributor1.

 For more information, visit www.9dot.it

For technical support, please contact:

Email: support@9dot.it

See section "Official Distributors"

8INJ MANUAL VER. 2 REV. 0

Safety

This manual contains important safety instructions that must be followed during installation, operation, and maintenance of

the product. Review the drawings and illustrations in this manual before proceeding. If you have any questions regarding the

safe installation or operation of this product, please contact 9dot or your nearest 9dot representative. Please keep it in a safe

place for future reference.

To reduce the risk of injury and to ensure continued safe operation of this product, the following terms have been incorporated

into this manual:

 ATTENTION: indicates safety information intended to prevent damage to people, materials or equipment

 IMPORTANT NOTE: additional clarifications on some features, terminology, reminders, etc.

Where they appear, please take more care and attention.

General warnings and precautions

You should read and understand the following warnings before installing the 9dot 8INJ and its components. Otherwise, it could

cause personal injury.

• Read and follow all instructions included in this manual.

• Don't work alone in dangerous conditions.

• Only qualified personnel may install, use, and repair this system and its components.

• Always assume electrical connections or conductors are live. Turn off all switches and recheck connections with a

voltmeter before installation or maintenance.

• Keep the installation area clean and dust-free during and after installation.

• Wear safety glasses when working in conditions that can be dangerous to the eyes.

Certifications and compliances

The equipment complies with FCC rules and regulations, European CE standard and RoHS directive.

Guarantee

To know the guarantee of our products, consult with our nearest distributor. See the “Official Distributors” section of this

document.

8INJ MANUAL VER. 2 REV. 0

General description

8INJ is a Power over Ethernet injector with integrated surge protection device belonging to the Smart Power Module System

family: a simple system designed to power up to 8 PoE devices where Plug n 'Play is required. Each PoE port works

independently and ensures the highest level of reliability and security.

There are power terminals for each port. Each power supply terminal has its own voltage present LED indicator.

Gigabit data port, galvanically isolated.

Gigabit port with PoE output to power different devices according to the chosen GigaKey. The output voltage of the PoE port

is equal to the input voltage at the power connector of the same port.

On the front there is a “9.KEY” LED that will indicate if the key is inserted correctly.

On the front there is a LED with the port number (1 to 8) which indicates if the port is powered.

LAN PORT

POE INJECTOR

GIGAKEY LED INDICATOR

Figure 1 – 8INJ front view

POWER CONNECTORS

PORT INDICATOR LED

INJ

MHUB

tWTUIlMM

mMtjm

iiiiiiinE

•

8INJ MANUAL VER. 2 REV. 0

This image indicates the correct position for inserting the GigaKeys, with the serigraphy facing upwards.

On the back of the unit there are slots for inserting the GigaKey keys that allow you to select the output pin of the PoE port

without the use of microswitches in order to provide PoE to a wide range of devices.

GIGAKEY

Figure 2 - 8INJ rear view

GIGAKEY SLOT

ajl

smaa

Mxmm

umana

minim

JllllllllL

umilili

minim

8INJ MANUAL VER. 2 REV. 0

8INJ features

Manages any kind of PoE

Each port can be configured to handle a different type of PoE injection map. The configuration of the power pin out is simple

and does not require any IT skills: just insert the specific electronic GigaKey and the port is configured.

Surge protection

Connected devices are protected from electrostatic overvoltage and electric shock. The combination of different types of

arresters maximizes efficiency and reduces the action time.

Galvanic Isolation

Galvanic isolation protects circuits and people from overvoltages between the input side and the output side. This results in

the best protection for your devices and for you.

More power

Up to 3A (145W@48V) per PoE port.

Compact design

The unit can manage up to 8 PoE ports. All functionalities are contained in a single rack unit.

8INJ MANUAL VER. 2 REV. 0

Label

This device is equipped with a label with the relevant information, which we will describe below.

As we can see, on the label it says:

• The product code: 8INJ, with its short description.

• The serial number.

• The part number P / N.

• Indications of compliance with FCC, CE and RoHS certifications and directives.

• Indications of power requirements and operating temperature range.

The image of the garbage container indicates that this equipment should not be placed in household containers. Instead, it

must be disposed of correctly in compliance with current regulations.

Figure 3 – 8INJ label example

INJ

Injector

Serial

RSC

Power

requirements

21.4

VDC

per

Port

Operating

temperature

Made

Italy

02101912110100

DOT

Sri

www

dot

8INJ MANUAL VER. 2 REV. 0

Technical specifications

8INJ

Product code 8INJ

ELECTRICAL SPECIFICATIONS

Operating voltage [V] Clamps: 10 to 60 AC/DC

Power connectors 8 x cable terminals 2 x 3.3 mm2

Typical current per port [A] (*)

Door led indicators

9.KEY:

key presence

;

number

presence power

port

Peak current protection [kA] 15

Overvoltage protection [V] 150

Protection mode All the lines (1-8) Protected (L-L) and (L-G)

SPD technology 2 phases: TVS and GDT

NETWORK SPECIFICATIONS

Ethernet connector 16 x jack RJ45 shielded (8 x LAN, 8 x PoE + data)

Speed network transmission 10BaseT; 100BaseT; 1000BaseT

MECHANICAL SPECIFICATIONS

Dimensions (LxPxH) [mm] 105 x 445 x 45

Weight [Kg] 2

Material Varnished iron

Mounting

ack 19”

ENVIRONMENTAL SPECIFICATIONS

Operating ambient temperature [° C] -20 to +55

Operating humidity without condensation [%] 5 to 95

IMPORTANT NOTES:

• (*) Although the typical value indicates that 3A current can flow continuously and indefinitely, this value must not be

exceeded.

• (*) The typical current of 3A per port can be reached if the PoE configuration chosen to power a device is via GigaKey:

GS-K-AB or GS-K-9.S because both use all four pairs of conductors for power supply. If instead we use the other

GigaKeys: GS-K-B or GS-K-BR, the typical current per port will be 1.5A2.

See the “GigaKey” section

8INJ MANUAL VER. 2 REV. 0

Installation

The 8INJ is designed for installation in a 19 "rack cabinet, however the fixing flaps can be rotated 90 ° for wall mounting.

IMPORTANT NOTE: Use only the parts supplied with the device for fixing the fins; the use of different parts can cause

irreparable damage to the device.

Before turning on the device it is advisable to connect the grounding terminal, fix the chassis to the cabinet or to the wall,

insert the chosen GigaKey keys and connect the signal cables, in particular:

• Wire the power supply.

• Connect the ethernet cables.

• Connect the power supply pins of the power supply to each port, paying attention to the polarity adopted.

• Connect the power supply to the electricity.

These cables are not supplied with the 8INJ.

Typical configuration

A typical configuration that can be obtained with this device is to combine it with NCore Lite, an Active Power Station 9dot

with 8 configurable power outputs for different voltages that allows modular power supply with ACDC or DCDC and has a

battery charger.

By powering an 8INJ with NCore Lite we can improve the benefits of both devices by remotely managing each output port and

thus having remote and indirect control over the input power of the 8INJ's PoE ports. That is, by controlling the NCore Lite

solution will allow you to control 8INJ ports as well.

This configuration transforms a PoE injector device into a remotely manageable integral power solution.

Figure 4 – configuration example 8INJ supplied by NCore Lite

Remote

Management

Batteries

FIAMM

Solar

Power

AVAVAVAVAVAVAV

MIA

llllllll

iUI

tmrn

•

Router

Switch

Passtrough

The

voltage

may

vary

depending

the

NCore

Lite

configuration

CAMBIUM

450

VPoE

Siae

Ceragon

Cambium

PoE
