3M Multimedia Projector S15 Manual

S15

Multimedia Projector

Operator's Guide

Thank you for purchasing this projector.

WARNING

►

Before using, read the "Product Safety Guide" and these

manuals to ensure correct usage through understanding. After reading, store

them in a safe place for future reference.

About this manual

Various symbols are used in this manual. The meanings of these symbols are

described below.

WARNING

This symbol indicates information that, if ignored, could possibly

result in personal injury or even death due to incorrect handling.

CAUTION

This symbol indicates information that, if ignored, could result

possibly in personal injury or physical damage due to incorrect

handling.



Please refer to the pages written following this symbol.

NOTE

• The information in this manual is subject to change without notice.

• The manufacturer assumes no responsibility for any errors that may appear in this manual.

• The reproduction, transmission or use of this document or contents is not permitted without

express written authority.

Trademark acknowledgment

• VGA and XGA are registered trademarks of the International Business Machines

Corporation.

• Apple and Mac are registered trademarks of Apple Computer, Inc.

• VESA and SVGA are trademarks of the Video Electronics Standard Association.

• Windows is a registered trademark of Microsoft Corporation.

• Internet Explorer is a trademark of Microsoft Corporation.

All other trademarks are the property of their respective owners.

SALE on Projector Bulbs at www.BulbAmerica.com

take additional 5% Off with coupon code 5PDF

About th

is manua

. . . . . . . . . .

Content

. . . . . . . . . . . . . . . . .

Projector feature

. . . . . . . . . .

About contents of package

. .

Part name

. . . . . . . . . . . . . . .

Projecto

. . . . . . . . . . . . . . . . . . . . .

Control

. . . . . . . . . . . . . . . . . . . . . .

Remote contro

. . . . . . . . . . . . . . . .

Preparations

. . . . . . . . . . . . . .

Fastening the lens cover

. . . . . . . . .

Fastening the lens cover . . . . . . . . . Fastening the lens cover

Putting batteries

. . . . . . . . . . . . . . .

Using the remote control

. . . . . . . . .

About the ﬁ lter cover for bottom-up use

. . .

Setting up

. . . . . . . . . . . . . . .

Arrangement

. . . . . . . . . . . . . . . . . .

Adjusting the projector's elevator

. . .

Connecting your devices

. . . . . . . .

Connecting power supply

. . . . . . .

Power on/of

. . . . . . . . . . . . .

Turning on the powe

. . . . . . . . . . .

r . . . . . . . . . . . r

urning off the powe

. . . . . . . . . . .

r . . . . . . . . . . . r

eratin

. . . . . . . . . . . . . . .

Adjusting the volum

. . . . . . . . . . .

Temporarily muting the soun

. . . .

Selecting an input signa

. . . . . . . .

Searching an input signa

. . . . . . .

Selecting an aspect rati

. . . . . . . .

Adjusting the zoom (magnifying

power)

. . . . . . . . . . . . . . . . . . . . . .

Adjusting the focus

. . . . . . . . . . . .

Using the automatic adjustment

feature

. . . . . . . . . . . . . . . . . . . . . .

Adjusting the positio

. . . . . . . . . .

Correcting the keystone distortion

. . .

Using the partial magnify feature

. . .

Freezing the scree

. . . . . . . . . . . .

Temporarily blanking the scree

. . .

Multifunctional setting

. . . .

Using the menu functio

. . . . . . . .

Contents

ASY

ENU

. . . . . . . . . . . . . . . . .

Aspect,

oom

, Keystone, Mode,

Bright, Contrast, Color, Tint,

Sharpness, Whisper, Mirror, Reset,

Filter time, Language,

Go to advanced menu

PICTURE men

. . . . . . . . . . . . . . .

Bright, Contrast, Gamma, Color temp,

Color, Tint, Sharpness, Progressive,

My memory

IMAGE men

. . . . . . . . . . . . . . . . .

Aspect, Over scan, V. position,

H. position, H. phase, H. size,

Auto adjust execute

INPUT men

. . . . . . . . . . . . . . . . .

Color space,

Video format,

Frame lock,

Information

SETUP men

. . . . . . . . . . . . . . . . .

Zoom,

Keystone, Whisper, Mirror,

Volume

SCREEN men

. . . . . . . . . . . . . . .

Language, Menu position, OSD bright,

Blank, Start up, MyScreen,

MyScreen lock, Message

OPTION men

. . . . . . . . . . . . . . . .

Auto s

earch

, Auto off, Lamp time,

Filter time, Service

Maintenanc

. . . . . . . . . . . . .

Lam

. . . . . . . . . . . . . . . . . . . . . . .

Air ﬁ lte

. . . . . . . . . . . . . . . . . . . . .

Other car

. . . . . . . . . . . . . . . . . . .

Troubleshootin

. . . . . . . . . .

Related message

. . . . . . . . . . . . .

Regarding the indicator lamp

. . . .

Phenomena that may easily be

mistaken for machine defect

. . . .

Speciﬁ cation

. . . . . . . . . . . .


