3idee Xia-27dm Manual de usuario

www.3idee.eu

xia-27dm VESA Adapter

Assembly instructions

The VESA adapter is compatible with the following Xiaomi (mi.com) products:

27inch desktop monitor.

The VESA adapter allows you to conveniently mount your XIAOMI brand monitor to

a monitor arm with a VESA hole pattern (75 x 75mm). Use the included screws and

nuts for this purpose.

If you want to mount your VESA adapter directly to the wall, use suitable screws

and dowels (not included).

2

Assembly instructions

Assembly instruction

Step 1

Place the monitor securely and flat on a soft surface. Now

press into the stand from below with a screwdriver to release

the click. Pull the stand upwards at the same time. (Figure 1)

Figure 1

Step 2

Mount the 3idee VESA adapter to your monitor arm or

directly to the wall. (Figure 2)

Figure 2

Step 3

Once you have completed the last step, please check if all

screws are tightened. (Figure 3)

Figure 3

3Assembly instructions

Step 4

Place the monitor on the adapter so that it audibly clicks into

place.

Note: Apply some pressure if necessary!

Please make sure that you secure the monitor well

with your hand while it is not fully engaged. (Figure

4)

Figure 4

Step 5

Now check if the monitor is properly locked into the VESA

adapter. You can try to pull the monitor towards you while it

should be firmly connected to the VESA adapter. (Figure 5)

Figure 5

4

Assembly instructions

Safety instructions

General notes

Make sure that all screws are tight and that the monitor audibly clicks into place during installation (if

available).

The material of the adapter is not heat resistant. Avoid direct heat around the adapter such as PC

exhaust or direct sunlight in summer.

PLA is UV resistant but not suitable for high temperatures.

Avoid jerky movements (pulling, tearing) on the PC monitor. This can affect the performance of the

VESA adapter.

Do not subject the PC monitor to excessive loads such as leaning or pushing. This can impair the

performance of the VESA adapter.

Material Notes

The adapter is made of high-quality polylactide (PLA) plastic. PLA is both a colorfast and UV-resistant

material and has low flammability. Polylactide has a low temperature resistance of approx. 45°C-55°C

and is therefore not suitable for use in the vicinity of direct heat and heat sources.

We wish you a lot of fun with your product.

Your 3idee Team

Responsible for this content:

3idee Technologies S.à r.l

5, ZA Um Lenster Bierg

L-6125 Junglinster

Luxembourg
