3idee HP-HP24F Manual de usuario

www.3idee.eu

Instruction manual

The VESA adapter is compatible with the following

products from hp: 24f, 22f, 27f, 22fw, 24fw, 27fw.

The VESA adapter allows you to conveniently mount your

HP brand monitor to a monitor arm with a VESA hole

pattern (75 x 75mm). Use the included screws and nuts for

this purpose.

If you want to mount your VESA adapter directly to the

wall, use suitable screws and dowels for this purpose. (not

included in the scope of delivery)

HP – HP24F

Assembly instruction

Step 1:

Remove the base of your monitor.

Step 2:

Mount the adapter on the VESA connector of your monitor arm or on the wall. (Figure 1).

Step 3:

Plug the monitor onto the adapter so that it audibly clicks into place.

Note: Apply a little pressure if necessary!

Figure 1

2

Instruction manual

Feel free to send your questions to:

[email protected]

Feel free to give us a call:

+352 661 878 191

You still have

questions?

Mail

Tel

Safety instructions

General Notes:

Material Notes:

– Make sure all screws are tight and the

monitor audibly clicks into place during

installation.

– The material of the adapter is not heat

resistant. Avoid direct heat in the vicinity of

the adapter, such as PC exhaust air or direct

sunlight.

The adapter is made of high quality

polylactide (PLA) plastic. PLA is both a

colorfast and UV-resistant material and

has low ammability. Polylactide has a low

temperature resistance of about 45°C-55°C

and is therefore not suitable for use around

direct heat and heat sources.

– Avoid jerky movements (pulling, tearing)

on the PC monitor. This can impair the

performance of the VESA adapter.

– Do not subject the PC monitor to

excessive loads such as leaning or pushing.

This may aect the performance of the

VESA adapter.

We wish you a lot of fun with your product.

Your 3idee Team

3idee SARL

19, Rue de Bitbourg

LU-1273 Luxembourg

3Instruction manual
