2N 9160341 Manual de usuario
2N Access Unit Installation
Manual
v.2.16
www.2n.com
2N Access Unit Installation Manual
2 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Content:
1. Product Overview
1.1 Components and Associated Products
1.2 Terms and Symbols
2. Description and Installation
2.1 Before You Start
2.2 Mechanical Installation
2.2.1 One Module Box
2.2.2 Two Module Box
2.2.3 Module dimensions
2.3 Electric Installation
2.3.1 Overvoltage Protection
2.4 Extending Module Connection
2.5 Mounting Completion
3. Maintenance
4. Technical Parameters
4.1 General drawings
5. Supplementary Information
5.1 Troubleshooting
5.2 Directives, Laws and Regulations
5.3 Other Countries' Legislation
5.4 General Instructions and Cautions
2N Access Unit Installation Manual
3 / 107
•
•
•
•
•
•
•
1. Product Overview
Here is what you can find in this section:
1.1 Components and Associated Products
1.2 Terms and Symbols
Basic Properties
2NAccess Unitis an elegant and reliable access IP system equipped with a number of useful
functions, which are not always common in devices of this category.
2NAccess Unitis a modular access system that meets all individual user needs. Unlike other
access systems available on the market,2NAccess Unitis not a single-module system with a
fixed functionality, but a user friendly modular system, allowing the user to assemble required
modules and accessories on a “plug and play” basis. This approach provides individual
configuration options and increase in functionality as necessary.
Keypadis a numeric keypad module that allows you to use the device for code lock switch
activation.
Integrated card reader moduleprovides the RFID card access control functionality. With
additional software settings, you can control more functions than the door lock using the card.
Electric lock switch –this switch can be can be controlled via a numeric keypad or Automation
actions. The switch can be completed with additional output modules if necessary. A wide range
of the switch mode settings provide an infinite number of applications.
Resistance–2NAccess Unitis designed as a robust, mechanically resistant access system,
which withstands any weather conditions without requiring additional accessories.
Installation of2NAccess Unitis very easy. All you have to do is assemble the required modules
and connect the system to your LAN via a mains cable. Being of the “plug and play” type, the
modules need not be configured individually. Feed the intercom either from a 12 V power supply
or directly from your PoE-supporting LAN.
To configure 2NAccess Unit, you need a PC equipped with any Internet browser. To manage
extensive intercom installations easily, use the2NAccess Commander.
Advantages of Use
Elegant design
Weather resistance
Variable mounting options (brick/plasterboard flush mounting, wall mounting)
Optional numeric keypad with backlight
Use of multiple modules of the same type – e.g. building entrance/exit card reader
2N Access Unit Installation Manual
4 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
Integrated electronic lock switches with wide setting options
Integrated RFID card reader module, Bluetooth module, fingerprint reader module or
touch keypad module
LAN (PoE) or external 12 V power supply
Configuration via web interface
HTTP server for configuration
SNTP client for server time synchronisation
SMTP client for e-mail sending
TFTP/HTTP client for automatic configuration and firmware update
1.1 Components and Associated Products
Basic Units
2N Part No. 9160341
2N® Access Unit 2.0 125 kHz
The card reader provides you with access control via
contactless cards or keyfobs. The module supports the 125
kHz EM4xxx.
2N Part No. 9160341US
Axis Part No. 02137-001
2N® Access Unit 2.0 125 kHz
The card reader provides you with access control via
contactless cards or keyfobs. The module supports the 125
kHz EM4xxx.
Reads HID Proximity
2N Access Unit Installation Manual
5 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 9160342
Axis Part No. 02143-001
2N® Access Unit 2.0 13.56 MHz, NFC/HCE ready
The card reader module provides you with access control via
contactless cardsorkeyfobs. The module supports the
following 13.56 MHz cards or other carriers (only card serial
number is read):
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
2N Part No. 9160342-S
Axis Part No. 02142-001
2N® Access Unit 2.0 13.56 MHz, NFC/HCE ready
The card reader module provides you with access control via
contactless cardsorkeyfobs. The module supports the
following 13.56 MHz cards or other carriers (only card serial
number is read):
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
2N Part No. 916013
Axis Part No. 01368-001
2N®Access Unit Bluetooth
The Bluetooth reader is used for reading users secure ID
numbers from the 2N®Mobile Key application of smart
phones Android and iOS.
2N Access Unit Installation Manual
6 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 916031
Axis Part No. 02263-001
2N®Access Unit 2.0 Fingerprint reader
The Fingerprint reader is used for verification of human
fingers for access control and intercom control.
2N Part No. 916032
Axis Part No. 02262-001
2N®Access Unit 2.0 Touch keypad
The numeric touch keypad module helps you control the
lock and use other code-accessible functions. The keypad
digits and symbols are backlit.
2N Part No. 9160344
Axis Part No. 02138-001
2N®Access Unit 2.0 RFID – 125 kHz, 13.56 MHz, NFC/HCE
The card reader provides you with access control via
contactless cards or keyfobs. The module supports the 125
kHz EM-41xx.
The card reader module provides you with access control via
contactless cardsorkeyfobs. The module supports the
following 13.56 MHz cards or other carriers (only card serial
number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
2N Access Unit Installation Manual
7 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 9160344-S
Axis Part No. 02146-001
2N®Access Unit 2.0 RFID – 125 kHz, secured 13.56 MHz,
NFC/HCE
The card reader provides you with access control via
contactless cards or keyfobs. The module supports the 125
kHz EM-41xx.
The card reader module provides you with access control via
contactless cardsorkeyfobs. The module supports the
following 13.56 MHz cards or other carriers (only card serial
number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
2N Part No. 9160335
Axis Part No. 02545-001
2N®Access Unit 2.0 Bluetooth & RFID – 125 kHz, 13.56
MHz, NFC/HCE
The bluetooth card reader module provides you with access
control via contactless cards or keyfobs. The module
supports the following125 kHz and13.56 MHz cards or other
carriers (only card serial number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
2N Access Unit Installation Manual
8 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 9160335-S
Axis Part No. 01851-001
2N®Access Unit 2.0 Bluetooth & RFID – 125 kHz, secured
13.56 MHz, NFC/HCE
The bluetooth card reader module provides you with access
control via contactless cards or keyfobs. The module
supports the following125 kHz and13.56 MHz cards or other
carriers (only card serial number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
2N Part No. 9160336
Axis Part No. 02546-001
2N®Access Unit 2.0 Touch keypad & RFID – 125 kHz, 13.56
MHz, NFC/HCE
The touch keypad and card reader module provides you
with access control via contactless cards or keyfobs. The
module supports the following125 kHz and13.56 MHz cards
or other carriers (only card serial number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
2N Access Unit Installation Manual
9 / 107
•
•
•
•
•
•
•
•
•
•
•
•
•
2N Part No. 9160336-S
Axis Part No. 01852-001
2N®Access Unit 2.0 Touch keypad & RFID – 125 kHz,
secured 13.56 MHz, NFC/HCE
The touch keypad and card reader module provides you
with access control via contactless cards or keyfobs. The
module supports the following125 kHz and13.56 MHz cards
or other carriers (only card serial number is read):
125 kHz
EM4xxx
13.56 MHz
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
2N®Mobile Key
HID SE (Seos, iClass SE, Mifare SE)
License
2N Part No. 916012
Axis Part No.
01369-001
2NAccess Unit license
2N Part No. 9160401
2N Access Unit Lift module license
•
Tip
Supported auxiliary modules: 2N®IP Verso modules are supported – RFID card
reader (125 kHz; 13.56 MHz), keypad, 5-button module, Wiegand, etc.
2N Access Unit Installation Manual
10 / 107
•
•
•
•
•
•
Frames
2N Part No. 9155011
Axis Part No. 01278-001
Flush mounting frame, 1-module
Covering frame for the 1-module brick/plasterboard
flush mounting box. This 1-module frame is used for
connection of an OUT card reader or keypad, for
example. Remember to order the frame when you
order a 1-module flush mounting box, Part No.
9155014.
2N Part No.9155011B
Axis Part No. 01279-001
Flush mounting frame, 1-module
Covering frame for the 1-module brick/plasterboard
flush mounting box. This 1-module frame is used for
connection of an OUT card reader or keypad, for
example. Remember to order the frame when you
order a 1-module flush mounting box, Part No.
9155014.
2N Part No. 9155012
Axis Part No. 01281-001
Flush mounting frame, 2-module
Covering frame for the 2-module brick/plasterboard
flush mounting box. Remember to order the frame
when you order a 2-module flush mounting box, Part
No. 9155015.
