2N IP Force
®
Security IP Intercom
Installation Manual
Version: 2.13
The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of
telecommunications equipment.
The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways,
private branch exchanges (PBX), and door and lift communicators. 2N
TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years
and represented a symbol of stability and prosperity on the telecommunications
market for almost two decades. At present, we export our products into over 120
countries worldwide and have exclusive distributors on all continents.
2N is a registered trademark of 2N TELEKOMUNIKACE a.s. Any product and/or other
®
names mentioned herein are registered trademarks and/or trademarks or brands
protected by law.
2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find
information and to answer your questions about 2N products and services. On www.
faq.2n.cz you can find information regarding products adjustment and instructions for
optimum use and procedures „What to do if...".
2N TELEKOMUNIKACE a.s. hereby declares that the 2N product complies with all
basic requirements and other relevant provisions of the 1999/5/EC directive. For the
full wording of the Declaration of Conformity see the CD-ROM (if enclosed) or our
website at www.2n.cz.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All
development, production and distribution processes of the company are managed by
this standard and guarantee a high quality, technical level and professional aspect of
all our products.
2N TELEKOMUNIKACE a.s., www.2n.cz 4/117
Content:
1. Product Overview
1.1 Components and Associated Products
1.2 Terms and Symbols
2. Description and Installation
2.1 Before You Start
2.2 Mechanical Installation
2.3 Electric Installation
2.4 Extending Module Connection
2.5 Button Tags
3. Function and Use
3.1 Configuration
3.2 Control
3.3 Maintenance
3.4 Downloads
4. Technical Parameters
5. Supplementary Information
5.1 Troubleshooting
5.2 Directives, Laws and Regulations
5.3 General Instructions and Cautions
2N TELEKOMUNIKACE a.s., www.2n.cz 5/117
1. Product Overview
Here is what you can find in this section:
1.1 Components and Associated Products
1.2 Terms and Symbols
Basic Features
2N IP Force
®is a highly resistant and reliable IP door access intercom provided with a
lot of useful above-standard functions. Supporting the SIP standard and being
compatible with the leading IP PBX and telephone suppliers, can make 2N IP Force
®
use of all VoIP services. can work as a standard or emergency door 2N IP Force
®
access intercom for buildings, entrances to premises or garages, manufacturing halls,
highways and so on.
2N IP Force
®is equipped with two very sensitive microphones and an up to 10W
loudspeaker. Thanks to an integrated acoustic echo cancelling (AEC) system, the
product provides mutual audibility even of persons talking at the same time under
normal conditions.
2N IP Force
®can be equipped with a colour wide-angle camera, which displays the
calling person on the called party's video telephone or PC monitor.
2N IP Force
® can be provided with 1, 2 or 4 pre-programmed buttons. You can set up
to three telephone numbers and time profiles for each of the buttons to increase the
accessibility of the called party.
2N IP Force
®can be equipped with a numerical keypad to be used as a code lock for
lock switch activating or telephone/subscriber number dialling.
2N TELEKOMUNIKACE a.s., www.2n.cz 6/117
2N IP Force
®is equipped with an electric lock switch. You can control the switch
using a numerical keypad or, during a call, using any telephone set. An additional
switch module can be installed if necessary. A wide range of settings allow for a
variety of applications.
2N IP Force
®can also be provided with RFID card reader modules.
2N IP Force
®is very easy to install. All you have to do is connect the system into your
LAN via a network cable and feed it from a 12 V power supply or your PoE supporting
LAN.
Configure using your PC via any web browser. Use the2N IP Force
®
to manage extensive systems easily and 2N Access Commander
® 2N IP Force
®
quickly.
Advantages of Use
Uncompromising Antivandal design
High coverage level – up to class IP69K
Variable mounting options (brick/plasterboard flush mounting, surface
mounting)
Sensitive microphone and powerful loudspeaker
Bidirectional communication – acoustic echo cancelling
Integrated colour camera with wide-angle lens
Optional dial buttons including name tags and backlight
Optional numerical keypad with backlight
Integrated electronic lock switches with wide setting options
Optional integrated RFID card reader module
LAN (PoE) or external 12 V power supply
Configuration via web interface or dedicated PC application
SIP 2.0 support
Up to 1999 telephone directory positions
Up to 20 user time profiles
Video codecs (H.263, H.263+, H.264, MPEG-4, JPEG)
Audio codecs (G.711, G.729, G.722, L16/16kHz)
HTTP server for configuration
SNTP client for time synchronisation with server
RTSP server for video streaming
SMTP client for e-mail sending
TFTP client for automatic configuration and firmware update
2N TELEKOMUNIKACE a.s., www.2n.cz 7/117
TFTP client for automatic configuration and firmware update
2N TELEKOMUNIKACE a.s., www.2n.cz 8/117
1.1 Components and Associated Products
2N IP Force
® Components and Associated Products:
2N TELEKOMUNIKACE a.s., www.2n.cz 9/117
Basic Units
One-Button
2N Part No. 9151101W
Axis Part No. 01336-001
1 button
control of two electric locks
possibility of connecting additional switch
10 W loudspeaker, IP69K
Part No. 9151101CW
IP69K
1 button
camera
10 W loudspeaker, IP69K
extra robust version
control of two electric locks
possibility of connecting additional switch
2N TELEKOMUNIKACE a.s., www.2n.cz 10/117
One-Button
2N Part No. 9151101CHW
Axis Part No. 01337-001
IP69K
1 button
HD camera
10 W loudspeaker, IP69K
extra robust version
control of two electric locks
possibility of connecting additional switch
2N Part No. 9151101RPW
Axis Part No. 01335-001
1 button, pictograms,
possibility of connecting card reader
control of two electric locks
possibility of connecting additional switch
10 W loudspeaker, IP69K
