100FIT 40T Manual de usuario
MOTORIZED TREADMILL
INSTRUCTION MANUAL -40T
PLEASE READ ALL INSTRUCTION IN THE OWNER'S MANUALCAREFULLY
BEFORE ASSEMBLY AND USE THE TREADMILL.
AND KEEP IT FOR FUTURE REFERENCE.
Context
1.Product outline ...............................................................01
2.Safety Instructions...........................................................04
3.Installation Instructions............................................................08
4.Computer Instructions...............................................................09
5.Daily Maintenance..................................................................35
6.Warm-up Demonstration.............................................................37
1. Product Outline
①Product functional area indicator
Screen
Storage box Storage box
Security lock
Armrest Armrest
Running belt
Side rail
Side rail
Power Switch
②Product accessories list
Name
Graphics
Quantity
Treadmill
1
Instructions
1
Security lock
1
Screw bag
1
Silicone oil
1
③Product parameters
Category
Single function
Color
Black
Net weight
38.5KG
Running belt
400*1200mm
Fold size
815*690*1325mm
Extend size
1520*690*1250mm
Peak horsepower
1.5HP
Speed range
08-12km/h
Max user weight
100KGS
Reference picture
④Exploded drawing
⑤Exploded drawing list
NO.
Name
Qty
NO.
Name
Qty
1
Base frame
1
2
Left column
1
3
Right column
1
4
Main frame
1
5
Console frame
1
6
Main frame horizontal tube
9
Motor
1
10
Running deck
1
11
Front roller
1
12
Rear roller
1
13
5MM L-shaped hexagon
wrench
1
14
Gas Spring
1
15
Cross open wrench
1
16
Heart rate steel sheet
4
17
∮3*74.5 Paddle button shaft
1
18
Console panel
1
19
Console plastic bottom cover
1
20
Console top cover
1
21
Panel bottom cover
1
22
Safety lock seat
1
23
LED Panel
1
24
Paddle button
2
25
Pad button holder
1
26
Heart rate grip
2
27
Left PU armrest
1
28
Right PU armrest
1
29
Base side cover left
1
30
Base side cover right
1
31
Frame rear foot pad left
1
32
Frame rear foot pad right
1
33
Motor top cover
1
34
Motor bottom cover
1
35
End cap left
1
36
End cap right
1
37
Side rail
2
38
R type clamp
2
39
Square inner tube
plug20*40*T1.5
2
40
Moving wheel
2
42
Running belt
1
43
Multi-slot belt
1
44
∮25*∮43*15Adjust the feet
4
45
∮28*11*M8*12Damping foot pad
1
46
∮28.5*∮4.5*11Frame feet
2
47
power cable
1
49
Power cord buckle
1
50
Magnetic ring∮31*∮19*H16
1
51
Red AC cable
1
52
Rocker switch
1
53
Safety lock
1
54
Safety lock copper sheet
2
55
keyboard
1
56
Panel core
1
57
Speaker
2
58
Shift button board
1
59
Lower part of the
communication line
1
60
Communication line
1
61
Controller
1
62
φ10.5-φ18*T1.5 Flat pad
4
63
M4*10 Phillips combination
screw
1
64
φ8-φ14*T2.0 Spring pad
2
65
M8 Lock nut
4
66
ST4.0*25 cross recessed pan
head tapping screws
3
67
M10 Lock nut
2
68
ST4.2*25 Phillips flat head self-
tapping self-drilling screws
10
69
M8*30 Hexagon socket head
screw, tooth length 15
1
70
M6*40Hexagon socket head
screw full thread
2
71
M10*90Hexagon socket head
screw, tooth length 20
2
72
M8*40Hexagon socket head
screw, tooth length 20
7
73
M6*45Hexagon socket head
screw full thread
3
74
M8*12Hexagon socket head
screw full thread
2
75
M6*25Countersunk hexagon
socket screw full thread
6
76
M6*50Hexagon socket head
screw full thread
1
77
ST2.5*6Cross recessed pan
head tapping screws
6
78
M6*30Countersunk hexagon
socket screw full thread
2
79
ST4.0*10Cross recessed pan
head tapping screws
17
80
ST3.0*8Cross recessed pan
head tapping screws
15
81
ST4.0*25Cross recessed pan
head tapping screws
4
82
ST4.0*16Cross recessed pan
head tapping screws
34
83
ST4.2*25Phillips flat head self-
tapping and self-drilling screws
8
84
ST4.2*16Phillips flat head self-
tapping and self-drilling screws
9
2.Safety Instructions
1.When you start training with this product, please consider your physical condition,
training properly and regularly to ensure that you have enough physical strength to
train. Wrong or excessive training will not help your health.
2.This product is not suitable for children. Physical discomfort or mental deficiency or
lack of common sense users are prohibited. Unless they are supervised or guided by
the person who responsible for their safety. Children need to be used under the
guardianship of adults and make sure that they will not play with equipment at
random.
3.This product is suitable for home use , not suitable for professional training and
testing, nor for medical purposes.
This product considers many safety issues in the design and manufacture, but to prevent
safety matters, please follow the instructions below, we will not bear any consequences
caused by abnormal operation.
In order to ensure your safety and avoid accidents, please read the instruction manual
carefully before use.
4.If the power line is damaged, it must be replaced by the manufacturer or a qualified
service person in order to avoid danger.
5.Please check all parts before use. And make sure the screws and nuts are tighten.
6.When running on a treadmill, wear comfortable tight clothes to avoid clothes being
caught by the machines. Do not let children or pets play around the treadmill to avoid
accidents.
7.Place the treadmill on a smooth, clean, level surface. Make sure there are no sharp
objects nearby. Please do not use it near water and heat sources.
8.When the product is not used for a long time, please place the product properly,
store and store it, pay attention to sunscreen, moisture and safe placement.
9.When the treadmill is running, it is for one person only.
10.If the product has a heart rate display, the heart rate is displayed as a simulated
parameter for reference only and cannot be used as clinical medical data.
11. The safety lock is an emergency stop device, which acts as an emergency stop
when an emergency occurs when using the product.
When the treadmill is not in use, please place the safety lock to prevent children and
people who are not suitable for using the treadmill from causing danger. .
12. When an emergency situation such as wrong speed or too fast occurs when
using the treadmill, you should quickly pull down the rope connected to the safety
lock of the machine, hold the handrail and jump off the running belt, step on the left
and right of the treadmill Above the side strip.
13. Before using the treadmill, please ensure a safe distance of 2000mmx1000mm
behind the equipment.
14. Please use the original accessories provided by the manufacturer, and it is
strictly forbidden to replace it without permission.
15. This product is an HC grade product with a maximum user weight of 100KG.
Special Notice:
1.Place the treadmill in a place where the plug can be plugged into the socket.
2.Plug the power line directly into the socket and do not allow looseness.
3.Please use qualified socket to avoid the danger.
4.If the plug and socket are not compatible, please do not change the plug and ask
the electrician to handle it.
5.Please use a power supply with a voltage of 220-240V.
6.Please do not let the power cord touch the running belt roller, do not put the power
supply on the running belt, do not use the
damaged plug.
7.Unplug the plug from the socket before cleaning and maintenance.
8.WARNING: if the plug is not pulled out, it may lead to personal injury and
equipment damage.
9.Please check each part carefully before use.
10.Please do not use this product outdoors, in high humidity and in the sun.
11.Please turn off the machine and remove the plug when you leave.
12.For your safety, the power plug of the machine must be grounded.
3.Installation Instruction
1
、
Single function installation instructions
1） Lift the treadmill out of the packing box (Figure 1), then lift the instrument and
the column (Figure 2), and fix the M8*40 screws and M8*15 screws on both sides of
the left and right columns (Figure 2) .
Figure 1 Figure 2
M8*15 screws
M8*40 screws
2. Fold up the meter (figure 3), fix the meter on the column with M8*15 screws,
tighten all the screws installed with an Allen wrench, and fix the left and right side
covers on the column with 4.2*16 screws , The assembly is complete (Figure 4).
Figure 3 Figure 4
M8*15 screws
4.2*16 screws
Right side cover
4.2*16 screws
Left side cover
